CATEGORY: Products » Dimmable BallastsDownloadable Brochure for Universal Lighting Technologies Ballastar T8 Light Level Switching Ballast The Ballastar T8 Light Level Switching Ballast from Universal Lighting Technologies allows users to switch light levels from 100% to 50%, or 100% to 60% to 30%, using standard wall switches and relays. The application benefits from uniform step dimming, with no dark spots and shadows in the light fixture or the illuminated space.
Universal offers a brochure describing the Ballastar T8 product line here.  Universal Lighting Technologies’ LevelPro incorporates true parallel lamp technology with starting under 700 milliseconds. Combined with dual lamp technology and high efficiency operation (complies with CEE and NEMA Premium) LevelPro offers a highly effective choice for your light level switching needs.
Check out the brochure for LevelPro here.  The QUICKTRONIC POWERSENSE T5HO universal voltage dimming system by OSRAM SYLVANIA is the industry’s first ballast that combines 2-wire power line and 0-10VDC control in one ballast type.
These high-efficiency ballasts operate linear fluorescent PENTRON® HO, PENTRON HO Circline, and DULUX® L T5 lamps over a 100-1% dimming range and provide true versatility in controls selection. With the patented lamp detection technology, these ballasts virtually eliminate variation in brightness from lamp to lamp and provide uniform lighting throughout the dimming range. Other features include: * maximum flexibility Click here to download free literature describing this product in detail.  For parallel lamp operation in analog dimming applications, Universal Lighting Technologies has introduced the new VariPRO 0-to-10-Volt Ballast for T8, T5, and T5HO linear fluorescent lamps. All models have extensive secondary application lists, including energy-saving lamps and single-lamp applications.
These ballasts provide an extraordinarily cost-effective solution for controllability down to 5% dimming with standard 0-10VDC controls. And parallel lamp operation assures reduced maintenance costs throughout the life of the ballast. VariPRO ballasts with precise filament control adhere to strict energy-saving requirements for the continued evolution of environmentally sustainable building practices. Ideal for foyers, offices, and other commercial spaces, VariPRO enables business owners and facility managers to take advantage of daylight harvesting and other advanced energy management techniques. With an ultra fast start time (<700 milliseconds), these CEE-listed ballasts are part of the NEMA Premium Electronic Ballast Program that identifies the most energy-efficient T8 fluorescent ballasts on the market today. Universal voltage and 347V models are available.  Philips Advance Optanium ballasts with step-dim capability for T5 fluorescent lamps represents an affordable, energy-efficient, and versatile lighting solution designed to meet California’s Title 24 requirements by allowing the end-user to reduce power by 50%.
Click here to download a free guide to the Optanium ballast. Universal Lighting Technologies brings parallel lamp operation to step-dimming applications with the new LevelPRO family of high-efficiency ballasts.
Flip one switch to cut power to lighting fixtures by 50 percent; flip another to cut the lights off entirely. And the entire lighting fixture remains evenly illuminated whether at full or half power. Ideal for classrooms, offices, and all spaces requiring compliance with energy codes for lighting control, the new LevelPRO ballast is available in either universal voltage (120-277 VAC) or 347 VAC input. Two new models are available. One drives T8 lamps at high ballast factor, and the other drives both T8 and T5 lamps at normal ballast factor. Both have extensive secondary application lists, including energy-saving lamps and single-lamp applications. These ballasts also feature ultra fast start times (<700 milliseconds), and they make it easy to comply with the strictest energy codes. LevelPRO is CEE listed and qualifies for the NEMA Premium Electronic Ballast Program as one of the most energy-efficient T8 fluorescent ballasts on the market today. And parallel lamp operation helps minimize maintenance costs throughout the life of the ballast. OSRAM SYLVANIA has announced availability of new QUICKTRONIC HELIOS controllable compact fluorescent ballasts that offer continuous dimming down to very low light levels of 3%. These multi-lamp ballasts for DULUX CF lamps operate one and/or two 13, 18, or 26 watt lamps or one 32 or 42 watt lamp.
QUICKTRONIC HELIOS ballasts include OSRAM SYLVANIA’s PROStart, programmed rapid start, and QUICKSENSE end-of-lamp life sensing features. A dual-mount function provides mounting flexibility and color coded connectors deliver easy installation. The ballasts are RoHS compliant, featuring lead-free solder and when paired with SYLVANIA DULUX lamps, the system is covered by the QUICK 60+ System Warranty of up to 24 months on the lamps and 60 months on the ballasts. Click here for more information about this product. OSRAM SYLVANIA has announced the QUICKTRONIC ICETRON 100W Dimming System, available to meet forthcoming control requirements in exterior lighting applications as well as to bring increased flexibility and light level adjustability for its 100W ICETRON induction lamp.
The QUICKTRONIC ICETRON 100W Dimming System offers two modes of control functionality–continuous dimming and step dimming–with a range of 100 to 40 percent power. These enhancements to the QUICKTRONIC ICETRON system meet controls requirements found in forthcoming energy code updates, such as CA Title 24, and deliver increased energy savings and design flexibility when compared with fixed power output systems. The electronic ballast is UL Type 2 wet location Listed, RoHS compliant and features IEEE/ANSI C62.41 Category C line transient protection, eliminating the need for additional surge suppression. Other benefits of the QUICKTRONIC ICETRON 100W Dimming System include reduced ballast weight, quiet operation and instant-on/instant re-strike, eliminating any delay when powering up the system. Like all ICETRON lamp and ballast pairings, the new dimming system is covered by OSRAM SYLVANIA’s QUICK60+® System Warranty of 5 years. For more information about this product, contact OSRAM SYLVANIA. This short video, produced by the Lighting Controls Association at the 2011 LIGHTFAIR event, introduces the building industry to Jump Lighting by Philips Ledalite.
Jump is a new portfolio of high performance direct luminaires that integrate daylight harvesting with the latest in light emitting diode (LED) or advanced fluorescent light sources. With more than two-thirds of today’s commercial buildings still using outdated lighting technologies, Jump offers building owners enhanced energy-efficiency without compromising on light quality. Jump delivers optimal lighting distribution, consistent color and exceptional system performance for commercial applications such as office, education, library, health and retail spaces. Its unique LEDLOGIQ™ design approach to LED features MesoOptics holographic nanotechnology, which makes spaces more visually comfortable by optimally blending light and color, controlling high angle glare and creating a precisely-controlled batwing distribution, while concealing the light source. In addition, Jump features integrated Response™ daylight harvesting sensors that can extend LED sustainability benefits by further reducing energy consumption up to another 35 percent. Available in a wide variety of light sources, patterns, colors and mounting options, the Jump portfolio also features an easy “plug and play” installation that simplifies maintenance, upgrades or replacement. The LED option has an expected life of 60,000 hours and carries a 5-year guarantee on the entire luminaire system (fixture, driver and LEDs). This short video, produced by the Lighting Controls Association at the 2011 LIGHTFAIR event, introduces the building industry to Universal Lighting Technologies’ Demand Control Lighting (DCL) solution.
DCL is designed to save time and money on installation, significantly lower energy consumption, and reduce payback periods. DEMANDflex ballasts are high-efficiency program-start ballasts with the flexibility to be tuned at the circuit level to set power levels during initial installation. When combined with DCL controls, they are part of the most cost-effective lighting energy management system available. DCL System Controls put you in command of your lighting energy costs. Reduce lighting power levels by up to 50% through a variety of control options. Incorporate scheduling and load shedding lighting strategies to reduce peak demand charges. Integrate DCL controls with other energy management controls for additional savings from daylight harvesting to occupancy sensors. DCL systems can be controlled from a local building management system or networked for control over the internet for demand response lighting control. |
  |
|||
|
